Product : Keystone Jack |
|
|
|
| |
| Cat.6A 180 Degree |
|
 |
|
Cat.6A180 Degree 110 Terminal Keystone Jack
|
| Cat.6A 90 Degree |
|
 |
|
Cat.6A90 Degree 110 Terminal Keystone Jack (KJ-31150D)
|
| Cat.6 Unshielded |
|
 |
|
Cat.6 Unshieded Keystone Jack
|
| Cat.6 Full Shielded |
|
 |
|
Cat.6 Full Shielded Keystone Jack
|
| Cat.5e/Cat.6 Toolless |
|
 |
|
Cat.5e/Cat.6 Toolless Keystone Jack
|
| 90。Standard Type |
|
|
|
SPECIFICATION
▲Terminal Type
110 Type: AT&T Type
Dual Type: Suitable For Both
110
Type & Krone Type
▲Acceptance
22~26 AWG Solid Wire
▲Match ANSI/TIA/EIA-568-A,
ISO/IEC 11801,EN50173
▲Color By Request
▲Special Design By Request
▲OEM Logo By Request |
PART NO.
KJ-abcd a=Grade
1:Cat5e 2:Cat6
b=Terminal Type
1:110Type 2:DualType
c=Shielding Type
1:Unshielding 2:Shielded
3:Full Shielded
d=Color
1:Black 2:Ivory
3:Red 4:Green
5:White 6:Blue
7:Orange 8:Yellow
9:Gray
e=IDC Cap
0:W/O 1:W/H |
|
|
| 90。 Narrow Type ( 18.5 mm ) |
|
 |
|
PART NO.
KJN-abcde
KJN:Narrow Keystone
a=Grade
1:Cat5e
2:Cat6
b=Terminal Type
1:110Type 2:Dual Type
c=Shielding Type
1:Unshielding 2:Shielded 3:Full Shielded
d=Color
1:Black 2:Ivory 3:Red 4:Green
5:White 6:Blue 7:Orange 8:Yellow
9:Gray
e=IDC Cap
0:W/O 1:W/H |
|
|
| 180。 Type |
|
 |
|
PART NO.
KJH-abcde
a=Grade 1:Cat5e 2:Cat6
b=Terminal Type
1:110Type 2:Dual Type ３:Tooless
c=Shielding Type
1:Unshielding 2:Shielded 3:Full Shielded
d=Color
1:Black 2:Ivory 3:Red 4:Green
5:White 6:Blue 7:Orange 8:Yellow
9:Gray
e=IDC Cap
0:W/O 1:W/H |
|
| 180。 Type |
|
 |
|
PART NO.
KJH-abcde
a=Grade 1:Cat5e 2:Cat6
b=Terminal Type
1:110Type 2:Dual Type ３:Tooless
c=Shielding Type
1:Unshielding 2:Shielded 3:Full Shielded
d=Color
1:Black 2:Ivory 3:Red 4:Green
5:White 6:Blue 7:Orange 8:Yellow
9:Gray
e=IDC Cap
0:W/O 1:W/H |
|
| Cat 3 TYPE |
|
|
|
PART NO.
KJ3-abcd
a=Terminal Type
1:110Type 2:Dual Type ３:Tooless
b=Position,Conductor
1:8p8c 2:8p4c 3:6p6c 4:6p4c
c=Golden plating
1:6u 2:15u 3:30u 4:50u
d=Color
1:Black 2:Ivory 3:Red 4:GreenS
5:White 6:Blue 7:Orange 8:Yellow
9:Gray |
|
|
|
|
| Toolless TYPE |
|
 |
|
PART NO.
KJT-abc
a=Grade
1:Cat5e 2.Cat6
b=Shielding Type
1:Unshielding 2:Shielded 3.Full Shielded
c=Color
1:Black 2:Ivory 3:Red 4:Green
5:White 6:Blue 7:Orange 8:Yellow
9:Gray |
|
| |
|
|
